Siemens 1600 Amp Breaker

Name: Siemens 1600 Amp Breaker - LEL Critical
SKU: C1502

Siemens 1600 Amp Breaker

Lot Number: C1502 Categories: Electrical & Switchgear, Sold Electrical and Switch Gears, Switchgear

Inquire Now

ADDITIONAL INFORMATION

Year	2010
Model Number	WLL2A316

Manufacturer	Siemens

DESCRIPTION

Integrated Cubicle Bus ETU776 Model: WLL2A316 Frame: WL62316 12SZ (99) Low Voltage AC Power Breaker Frame Frame Size: 1600A (8) 800 AMP Plugs (91) 1200 AMP Plugs Frequency: 50/60 Hz Volts max.: 254, 508 V ~ Inst. 100 kA Symm. Short Time: 85 kA Symm. Volts max.: 635V ~ Inst. 85 kA Symm. Short Time: 85 kA Symm. Instr. Book & Outline Dwg: CBIM-02000-0204 Mfg. Date: 2010-07-22 ID – No. : 4001300722010 L2A316QVKCXCZXC

Description
Additional information

Description

Integrated Cubicle Bus
ETU776
Model: WLL2A316
Frame: WL62316
12SZ
(99) Low Voltage AC
Power Breaker Frame
Frame Size: 1600A
(8) 800 AMP Plugs
(91) 1200 AMP Plugs
Frequency: 50/60 Hz
Volts max.: 254, 508 V ~
Inst. 100 kA Symm.
Short Time: 85 kA Symm.
Volts max.: 635V ~
Inst. 85 kA Symm.
Short Time: 85 kA Symm.
Instr. Book &
Outline Dwg: CBIM-02000-0204
Mfg. Date: 2010-07-22
ID – No. : 4001300722010
L2A316QVKCXCZXC
