Description
Maximum Allowable Working Pressure: 635 PSIG
Frame Rated Speed (RPM): 1200
Minimum Speed (RPM): 900
Maximum Rod Load Tension: 21,000 LBS
Maximum Rod Load Compression 23,000 LBS
Ariel Shipping Date: May/June 2010
Normal Lube Oil Pressure: 60 PSI
Maximum Lube Oil Temperature: 190F
Lube Oil Pressure Shutdown Setting: 35 PSI
Motor:
Siemens
HP 600
Volts: 460
RPM: 887
Frame: 5810S
Stage 1 and Stage 2:
Bore: 19.000 IN
Class: RJ-PRC
Stroke: 3.50 IN
Rated RPM: 1200
Maximum Allowable Working Pressure: 200 PSIG
Pist. End CL HE: .070-.130, CE .04
Minimum Volume CL(%) HE: 24.4, CE: 24.9
Stage 3:
Bore: 13.500 IN
Class: RJ-PRC
Stroke: 3.50 IN
Rated RPM: 1200
Maximum Allowable Working Pressure: 300 PSIG
Pist. End CL HE: .070-.130, CE .04
Minimum Volume CL(%) HE: 23.6, CE: 25.1
Cylinder Serial Number: C-116342
Stage 4:
Bore: 9.750 IN
Class: RJ-PRC
Stroke: 3.50 IN
Rated RPM: 1200
Maximum Allowable Working Pressure: 635 PSIG
Pist. End CL HE: .070-.130, CE .04
Minimum Volume CL(%) HE: 18.8, CE: 20.2
Cylinder Serial Number: C-116340
Stage 5:
Bore: 7.000 IN
Class: RJ-PRC
Stroke: 3.50 IN
Rated RPM: 1200
Maximum Allowable Working Pressure: 845 PSIG
Pist. End CL HE: .070-.130, CE .04
Minimum Volume CL(%) HE: 26.6, CE: 28.9
Cylinder Serial Number: C-116339
