Description
Disclaimer: The listing picture is a stock photo and does not exactly resemble the final product. Expected delivery in Q3 of 2024.
———————————
System Voltage – 480Y/277V 3Ph 4W 60Hz
System Ampacity – 2000A
Source Description – Single Main
Bussing – Silver Plated Copper
Neutral Bus – 100%
Max Available Fault Current (RMS) – 100kA
Enclosure – Type 1
Accessibility: Front Only
Exterior Paint Color – ANSI 49
Lineup with MasterPact MTZ Breaker(s)
Ground Lug provided for each device
Copper Ground Bus
Dimensions
———————————
3 – 36″ Wide Section(s)
3 – 36″ Deep Enclosure(s)
Dimensions: 108.00″ W X 36″ Max D X 91.5″ H
Approximate Weight: 3044.00 lbs / 1380.76 kgs
Incoming Requirements
———————————
Suitable for Use As Service Entrance
Entry Point: Left of Lineup, Through the Bottom
Connection Type: Cable Mains
———————————
1 – 2000AF/2000AT 100% 3 Pole Stored Energy,
Fixed Mounted Circuit Breaker, UL: Type
MTZ 2
Micrologic X 6.0, Long Time, Short Time,
Instantaneous, Ground Fault
DM – Energy Reduction Maintenance Setting
(ERMS)
Auxiliary Switches 4A-4B
Overcurrent Trip Switch 1A/1B Form C
Contact (SDE)
Programmable Contact Module, ESM
Contact Wear Indication – Visual
Energy Reduction Maintenance Switch
Feeders
———————————
1 – 1600AF/1600AT 100% 3 Pole Stored Energy,
Fixed Mounted Circuit Breaker, UL: Type
MTZ 2
Micrologic X 6.0, Long Time, Short Time,
Instantaneous, Ground Fault
DM – Energy Reduction Maintenance Setting
(ERMS)
Auxiliary Switches 4A-4B
Overcurrent Trip Switch 1A/1B Form C
Contact (SDE)
Programmable Contact Module, ESM
Contact Wear Indication – Visual
Energy Reduction Maintenance Switch
2 – 250AS/250AT 480V 80% Rated 100 kA 3 Pole
UL, Group Mounted Electronic Trip
Circuit Breaker: Type JL
Standard Trip Unit, Long Time, Short
Time, Instantaneous
Overcurrent Trip Switch 1A/1B Form C
2 – 400AS/400AT 480V 80% Rated 100 kA 3 Pole
UL, Group Mounted Electronic Trip
Circuit Breaker: Type LL
Standard Trip Unit, Long Time, Short
Time, Instantaneous
2 – 600AS/600AT 480V 80% Rated 100 kA 3 Pole
UL, Group Mounted Electronic Trip
Circuit Breaker: Type LL
Standard Trip Unit, Long Time, Short
Time, Instantaneous
2 – 800AS/800AT 480V 80% Rated 100 kA 3 Pole
UL, Group Mounted Electronic Trip
Circuit Breaker: Type PL
Standard Trip Unit, Long Time, Short
Time, Instantaneous
