Description
Diesel Genset: 60Hz-1250/1135kW | Model 1250DQGAE | U.S. EPA | Stationary Emergency Application | Diesel Genset: 60Hz-1250kW | Duty Rating-Standby Power | Listing-UL 2200 | Emissions Certification | EPA | Tier 2 | NSPS CI Stationary Emergency | Voltage-277/480 | 3 Phase | Wye | 4 Wire | Output Terminals-2-Hole Lug | NEMA | Alternator-60Hz | 3Ph | 480V | 80C-S | Generator Set Control-PowerCommand 3.3 | Paralleling | Display Language-English | Meters-AC Output | Analog | Display-Control | LCD | AmpSentryTM Protective Relay | Alarm-Audible | Engine Shutdown | Signals – Auxiliary | 8 Inputs/8 Outputs | RELAYS-USER CONFIGURED | Heater-Alternator | 120 Volt AC | CB or EB or TB-Left Only | Terminal Box-Low Voltage | Left | CB or EB or TB-Top Entry | Left | Control Mounting-Front Facing | Separator-Fuel/Water | Fuel Filters-Engine | Triplex | Engine Starter-24 VDC Motor – Dual Starters | Battery Charging Alternator-Normal Output | Engine Cooling-Remote Cooler | Shutdown-Low Coolant Level | Coolant Connections-Flanged (ASA) | Engine Air Cleaner-Normal Duty | Filters-Engine Oil | Full Flow and Bypass | Test Record-Safety Shutdowns | Test Record-Certified | Genset Warranty- Base | Literature-English | Packing-None | Vibration Isolators-Normal Duty | Common Parts Listing | Product Revision – E | Vertical Core | Horizontal Air Flow Remote Radiator with Surge Tanks and Motor Starting Kit – Ships Loose (Surge Tank Length = 72.75”) | Critical Grade Muffler & Stainless Flex Connection – Ships Loose | STS-300 Gallon UL 142 Day Tank – Ships Loose (no supply pump) – Ships Loose | AUX 102 Expansion Control Kit | 8 Discrete/Analog Input/ 8 Form-C Output-PCC 1.x/2.x/3.x | Modbus to BACnet Converter – Ships Loose
